Fast fot GN340.5 i rostfritt stål
Fot i rostfritt stål med glidskydd i gummi.
Rekommenderad maxvinkel ≈ 6°.
Beställningsexempel: GN340.5 80-M20X150
| d1 | d2 | l1 | l2 | l3 | l4 | sw1 | sw2 | Max statisk belastning \[N\] | ||||
| 50 | M16 | 75 | \- | 125 | 150 | 29 | 14,5 | 3,5 | 8 | 12 | 30000 | |
| 60 | M16 | 75 | \- | 125 | \- | 30 | 16 | 4 | 8 | 12 | 28000 | |
| 80 | M16 | 75 | \- | 125 | 150 | 32 | 18 | 5 | 8 | 12 | 19000 | |
| 80 | M20 | 75 | \- | 125 | 150 | 33 | 18 | 5 | 10 | 15 | 19000 | |
| 80 | M24 | \- | \- | \- | 150 | 36 | 18 | 5 | 12 | 19 | 19000 | |
| 100 | M16 | 75 | \- | 125 | 150 | 34 | 20 | 6 | 8 | 12 | 18000 | |
| 100 | M20 | \- | \- | 125 | 150 | 35 | 20 | 6 | 10 | 15 | 18000 | |
| 100 | M24 | \- | \- | \- | 150 | 38 | 20 | 6 | 12 | 19 | 18000 | |
| Mängdrabatt | ||||
|---|---|---|---|---|
| Art.nr | Benämning | Kr/st ex.moms | -10% | -20% |
| GN340.5 50-M16X75 | Fot, rostfritt stål m.glidskydd | 224.80 | 10 st | 50 st |
| GN340.5 50-M16X125 | Fot, rostfritt stål m.glidskydd | 236.10 | 10 st | 50 st |
| GN340.5 50-M16X150 | Fot, rostfritt stål m.glidskydd | 236.50 | 10 st | 50 st |
| GN340.5 60-M16X75 | Fot, rostfritt stål m.glidskydd | 212.00 | 10 st | 50 st |
| GN340.5 60-M16X125 | Fot, rostfritt stål m.glidskydd | 237.40 | 10 st | 50 st |
| GN340.5 60-M16X150 | Fot, rostfritt stål m.glidskydd | 237.30 | 10 st | 50 st |
| GN340.5 80-M16X75 | Fot, rostfritt stål m.glidskydd | 245.50 | 10 st | 50 st |
| GN340.5 80-M16X125 | Fot, rostfritt stål m.glidskydd | 276.00 | 10 st | 50 st |
| GN340.5 80-M16X150 | Fot, rostfritt stål m.glidskydd | 269.00 | 10 st | 50 st |
| GN340.5 80-M20X75 | Fot, rostfritt stål m.glidskydd | 301.30 | 10 st | 50 st |
| GN340.5 80-M20X125 | Fot, rostfritt stål m.glidskydd | 355.00 | 10 st | 50 st |
| GN340.5 80-M20X150 | Fot, rostfritt stål m.glidskydd | 329.60 | 10 st | 50 st |
| GN340.5 80-M24X100 | Fot, rostfritt stål m.glidskydd | 392.00 | 10 st | 50 st |
| GN340.5 80-M24X150 | Fot, rostfritt stål m.glidskydd | 415.00 | 10 st | 50 st |
| GN340.5 100-M16X75 | Fot, rostfritt stål m.glidskydd | 325.90 | 10 st | 50 st |
| GN340.5 100-M16X125 | Fot, rostfritt stål m.glidskydd | 357.00 | 10 st | 50 st |
| GN340.5 100-M16X150 | Fot, rostfritt stål m.glidskydd | 359.00 | 10 st | 50 st |
| GN340.5 100-M20X75 | Fot, rostfritt stål m.glidskydd | 374.00 | 10 st | 50 st |
| GN340.5 100-M20X125 | Fot, rostfritt stål m.glidskydd | 421.00 | 10 st | 50 st |
| GN340.5 100-M20X150 | Fot, rostfritt stål m.glidskydd | 414.00 | 10 st | 50 st |
| GN340.5 100-M24X100 | Fot, rostfritt stål m.glidskydd | 479.00 | 10 st | 50 st |
| GN340.5 100-M24X125 | Fot, rostfritt stål m.glidskydd | 513.00 | 10 st | 50 st |
| GN340.5 100-M24X150 | Fot, rostfritt stål m.glidskydd | 495.00 | 10 st | 50 st |
